Tech specs
Brand
Fortinet
Product Line
Fortinet FortiGate
Model
80F
Manufacturer
Fortinet
Processor Brand
Fortinet
Processor Type
FortiASIC SOC4
Processors Installed
1
Connectivity Technology
Wired
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
3G/4G USB Dongle Support, Fanless, VPN support
Form Factor
Desktop
Network Standard
IPSec
Product Type
Security appliance
Interface Provided
1 x console - RJ-45, 1 x USB 3.0 - Type A, 2 x 1000Base-T/1000Base-X - RJ-45/SFP (mini-GBIC) (WAN), 8 x 1000Base-T - RJ-45
Frequency
50/60 hertz
Power Consumption Operational
15.4 watt
Power Supplies Installed
2
Encryption
SSL, TLS 1.3
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Capacity
Client to gateway IPSec VPN tunnels: 2500, Concurrent SSL VPN users: 200, Concurrent TCP sessions: 1500000, Firewall policies: 5000, Gateway to gateway IPSec VPN Tunnels: 200, New TCP sessions per second: 45000, Number of FortiAP devices (tunnel mode): 16, Number of FortiAP devices: 32, Number of FortiToken devices: 500, SSL inspection concurrent sessions: 100000, SSL inspection CPS: 700, Virtual domains: 10
Device Type
External power adapter
Packaged Quantity
1
Service Activation
No
Network Device
Application control throughput: 1.8 Gbps, CAPWAP throughput: 9 Gbps, Firewall latency (64-byte UDP): 4 µs, Firewall throughput (1518-byte UDP): 10 Gbps, Firewall throughput (512-byte UDP): 10 Gbps, Firewall throughput (64-byte UDP): 7 Gbps, Firewall throughput: 10.5 Mpps, IPS throughput: 1.4 Gbps, NGFW throughput: 1 Gbps, SSL inspection throughput: 715 Mbps, Threat protection throughput: 900 Mbps, VPN throughput (512-bit IPSec): 6.5 Gbps, VPN throughput (SSL): 950 Mbps
Height
1.5 inch
Weight
5.29 lbs
Width
8.5 inch
Depth
6.3 inch
Color Category
White
Compliant Standards
BSMI, CB, cUL, FCC, ICES, ICSA Antivirus, ICSA Firewall certified, ICSA IPS, ICSA IPSec certified, ICSA SSL-VPN, RCM, UL, VCCI
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
