Tech specs
Manufacturer
Fortinet
Brand
Fortinet
Product Line
Fortinet FortiWiFi
Model
50E
Packaged Quantity
1
Antenna Form Factor
External detachable
Antenna Qty
2
Built-in Devices
LED panel
Type
None
Performance
Firewall latency (64-byte UDP): 180 µs, Firewall throughput (1518-byte packet size): 2.5 Gbps, Firewall throughput: 375 Kpps, IPS throughput (HTTP): 800 Mbps, IPS throughput: 800 Mbps, IPSes throughput (512-byte packet size): 200 Mbps, SSL inspection throughput: 250 Mbps, VPN throughput (SSL): 100 Mbps
Capacity
Client to gateway IPSec VPN tunnels: 250, Firewall policies: 5000, Gateway to gateway IPSec VPN Tunnels: 20, Maximum number of concurrent sessions: 1800000, New sessions per second: 21000, Number of FortiAP devices: 10, Number of FortiClient devices: 200, Number of FortiToken devices: 100, Virtual domains: 5
Type
Security appliance
Form Factor
External
Connectivity Technology
Wired, Wireless
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wireless Protocol
802.11a/b/g/n
Switching Protocol
Ethernet
Network / Transport Protocol
IPSec, TCP/IP, UDP/IP
Remote Management Protocol
CLI
Status Indicators
Alarm, HA, Link/activity, Port transmission speed, Power, Status, WLAN
Features
3G/4G USB Dongle Support, Anti-spam protection, Antivirus analysis, Application filtering, Firewall protection, High Availability, Intrusion Prevention System (IPS), IPSec Virtual Private Network (VPN), Manageable, Switching, URL filtering, Wall mountable, Web threat protection
Compliant Standards
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Interfaces
1 x console - RJ-45, 1 x USB - Type A, 2 x 1000Base-T - RJ-45 (WAN), 2 x antenna, 5 x 1000Base-T - RJ-45
Type
FortiOS 5
Cables Included
1 x console cable, 1 x network cable
Type
External power adapter
Frequency Required
50/60 hertz
Power Consumption Operational
18 watt
Included Accessories
Wall mounting kit
Encryption Algorithm
256-bit AES, SHA-1, SSL
Compliant Standards
CB, C-Tick, cUL, FCC Part 15 B, ICSA Antivirus, ICSA Firewall certified, ICSA IPSec certified, ICSA Network IPS, UL, VCCI
Width
8.5 inch
Depth
5.5 inch
Height
1.4 inch
Weight
32.66 ounce
Min Operating Temperature
32 degree Fahrenheit
Max Operating Temperature
104 degree Fahrenheit
Humidity Range Operating
20 - 90% (non-condensing)
