Tech specs
Brand
Grandstream
Product Line
Grandstream
Model
HT814 V2
Manufacturer
Grandstream
Compliant Standards
IEEE 802.1p, IEEE 802.1Q
Connectivity Technology
Wired
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
DHCP support, DiffServ support, Fax over IP, MPLS QoS, NAT support, Quality of Service (QoS), Reset button, SRTP support, Syslog support, Type of Service (ToS), VLAN support
Form Factor
External
IP Telephony Features
3-way conferencing, Call forwarding, Call hold, Call transfer, Call waiting, Caller ID, Dual-Tone Multi-Frequency (DTMF) dialing, Dynamic jitter buffer, Echo cancellation, RFC 2833 support, SIP info, T.38 FAX
Network Standard
ARP, DHCP, DNS, IPoE, NTP, RARP, RTCP, RTP, SIPS, TCP/IP, UDP/IP
Ports
4
Product Type
VoIP gateway
Remote Management
HTTP, HTTPS, ICMP, SNMP, Telnet, TFTP, TR-069
Status Indicators
Phone, Power, WAN/LAN
Interface Provided
2 x 1000Base-T - RJ-45, 4 x FXS - RJ-11
Frequency
50/60 hertz
Required Voltage
AC 100-240 volt
Encryption
AES, TLS
Framing Format
G.711, G.723.1
Max Operating Temperature
122 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Voice Codec
G.711, G.722, G.723.1, G.726, G.726-32, G.729ab, iLBC, Opus, T.38
Device Type
External power adapter
Packaged Quantity
1
VoIP
Yes
VoIP Protocols
SIP
Cables
1 x network cable
Height
1.1 inch
Weight
10.23 ounce
Width
5.1 inch
Depth
3.5 inch
Color Category
Black
Compliant Standards
CAN ICES-003(B)/NMB003(B), Directive 2004/108/EC, Directive 2006/95/EC, Directive 2014/30/EU, Directive 2014/35/EU, EAC, EN 55032:2015+A1:2020, EN 55035:2017+A11:2020, EN 61000-3-3:2013+A2:2021+AC:2022-01, EN IEC 61000-3-2:2019+A1:2021, EN IEC 62368-1:2020+A11:2020, FCC Part 15 Class B, RCM
Service & Support Details
Limited warranty - 1 year
Limited Warranty
1 Year
