Tech specs
Brand
Hanwha Vision
Product Line
Hanwha Vision
Model
PNO-A9311R
Manufacturer
Hanwha
Flash Memory Installed
1024 megabyte
Memory Cards Supported
microSD Card, microSDHC Card, microSDXC Card
RAM Installed
4 GB
Network Interface
Ethernet 10Base-T/100Base-TX/1000Base-T
Protocols
ARP, Bonjour, DDNS, DHCP, DNS, EAP, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, LLDP, MQTT, NTP, QOS, RTCP, RTP, RTSP, SMTP, SNMP 1, SNMP 2c, SNMP 3, SRTP, SSL, TCP/IP, TLS, UDP, UDP/IP, UPnP
Connectivity Technology
Wired
Ports
Audio line out, Audio line-in/microphone, Composite video - BNC, LAN/power - RJ-45, USB - Micro-USB Type B
Image Sensor Size
1/1.8"
Image Sensor Type
CMOS
Audio Formats
AAC-LC, ADPCM, G.711, G.726, U-LAW
Audio Support
Yes
Camera Mechanical Design
Fixed
Digital Video Capture Resolution
1024 x 768, 1280 x 1024, 1280 x 720, 1280 x 960, 1600 x 1200, 1920 x 1080, 2048 x 1536, 2560 x 1440, 2592 x 1944, 2688 x 1520, 3072 x 1728, 3840 x 2160, 640 x 360, 640 x 480, 720 x 480, 720 x 576, 800 x 448, 800 x 600
Max Frame Rate
30 frames per second
Max Video Resolution
3840 x 2160
Motion Detection
Yes
Shutter Speed (Max)
1/12000 second (time unit)
Shutter Speed (Min)
1/5 second (time unit)
Video Signals
Composite video, USB
Camera Type
Network surveillance camera
Night Vision
Yes
Low Voltage Power
DC 12 V / PoE Plus
Power Consumption Operational
14 watt
Angular Field of View (D, Max, Degree)
69.18
Angular Field of View (D, Min, Degree)
2.52
Angular Field of View (H, Max, Degree)
60.92
Angular Field of View (H, Min, Degree)
2.2
Angular Field of View (V, Max, Degree)
35.26
Angular Field of View (V, Min, Degree)
1.24
Auto Iris Control
P-Iris
Camera Iris
Auto iris
Encryption
FIPS 140-2 Level 2
Focal Length Control
Motorized zoom
Form Factor
Bullet
Infrared Distance
230 ft
Infrared LEDs
Yes
Lens Aperture
F/1.36-4.6
Max Focal Length
214.7 millimetre
Max Operating Temperature
131 degree Fahrenheit
Min Focal Length
6.91 millimetre
Min Focus Distance
10 ft
Min Operating Temperature
-40 degree Fahrenheit
Minimum Illumination
0 lux - B&W - infrared LEDs on, 0.0075 lux - B&W - F1.36 - 30 IRE - shutter 1/30 sec, 0.075 lux - color - F1.36 - 30 IRE - shutter 1/30 sec
Operating Humidity
0 - 90% RH
Optical Zoom
31
Sensor Size (metric)
14.1 mm (1/1.8")
Video Formats
H.264, H.265, MJPEG
Video Input
Color
Alarm Input Quantity
1
Alarm Output Quantity
1
Features
Audio Detection, Backlight Compensation (BLC), Constant Bit Rate (CBR), Defocus Detection, Digest authentication, Digital Image Stabilization (DIS), Entrance / exit detection, Face Detection, Gain Control, Hallway View, Heat Map, Image flip, Image mirror, Intrusion detection, IP address filtering, License plate detection, Loitering detection, Motion Detection, Multicast Streaming, Object Detection, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, Person Detection, Privacy Mask Function, Queue management, Samsung Super Dynamic Range (SSDR), Samsung Super Noise Reduction (SSNR) V, Secure Boot, Shock detection, Social distancing detection, Sound classification, Tamper-detection, Unicast Streaming, User access log, Variable Bit Rate (VBR), Vehicle Detection, Virtual Line detection, White balance, Wide Dynamic Range (WDR), WiseNR II, WiseStream II support, WiseStream III support
Packaged Quantity
1
Height
14.1 inch
Weight
7.05 lbs
Width
5.4 inch
Depth
5.4 inch
Color
RAL 9003, White
Color Category
White
Compliant Standards
AS/NZS CISPR 32 Class A, CAN/CSA-C22.2 No. 62368-1, EN 50130-4, EN 55032 Class A, EN 61000-3-2, EN 61000-3-3, FCC 47 CFR Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), IEC/EN 62471, IEC/EN 63000, IK10, IP66, IP67, NEMA Type 4X, UKCA, UL 62368-1, VCCI-CISPR 32 Class A
