Tech specs
Brand
Honeywell
Product Line
Honeywell
Model
PM45
Manufacturer
Honeywell
Flash Memory Installed
512 megabyte
Memory Technology
SDRAM
RAM Installed
256 megabyte
Product Type
Print server
Remote Management
HTTP, SNMP 1, SNMP 2c, SNMP 3
Interface
Gigabit LAN, Serial, USB 2.0, USB 2.0 host
Interface Required Connections
1 x Gigabit LAN - RJ-45, 1 x RS-232 - 9 pin D-Sub (DB-9), 1 x USB 2.0 - 4 pin USB Type B, 2 x USB 2.0 host - 4 pin USB Type A
Max B/W Print Resolution
300 dpi
Max H-Document Size
4.5 in
Max Mono Print Speed
708.7 Inches per minute
Max Print Length
86.6 inch
Max Print Size
Roll (4.5 in)
Max Roll Diameter
8.4 inch
Maximum Print Width
4.16 inch
Min H-Document Size
0.75 in
Print Output Type
Monochrome
Print Speed
Up to 708.7 inch/min - max speed - 300 dpi
Wireless Print Technology
Wired
Barcode Symbology Supported
AIAG, Aztec code, Codabar, Code 11, Code 128, Code 16K, Code 39, Code 49, Code 93, Data Matrix, EAN/JAN, Grid Matrix Code, GS1 DataBar, HIBCC, Industrial 2 of 5, Interleaved 2 of 5, ISBT 128, LOGMARS, Matrix 2 of 5, MaxiCode, MicroPDF417, MSI-Plessey, PDF417, PLANET, Plessey, Postnet, QR code, Standard 2 of 5, UCC/EAN-128, UPC
Media Feeders
1 x manual - 1 roll - Roll (4.5 in)
Media Size Class
Other
Media Sizes
Roll (0.75 in - 4.5 in)
Media Type
Other
Frequency
50/60 hertz
Power Consumption Operational
270 watt
Power Device Type
Power adapter
Required Voltage
AC 100-240 volt
Power Device Form Factor
External
Language Emulation
DPL, Extensible Mark-up Language (XML), Intermec Direct Protocol, Intermec Fingerprint, Intermec Printer Language (IPL), PDF, ZSim2
Max Operating Temperature
104 degree Fahrenheit
Media Type
Fanfold paper, Labels, Linerless labels, Tag stock, Tickets
Min Operating Temperature
41 degree Fahrenheit
Operating Humidity
20 - 80% (non-condensing)
Roll Core Diameter
1.5 in, 3 in
Built-in Devices
LCD touch screen
Country
United States
Label Printer Features
Black Mark sensor, Gap sensor, Label Taken Sensor (LTS), Notch sensor, Paper low sensor, Rewinder, Ribbon end sensor
Office Machine Type
Printer
Printer Product Type
Label printer
Scanner Functionality
None
Printer Functions
Printer
Packaged Quantity
1
Print Technology
Thermal Transfer
Printer Accessories Included
Fixed media hanger
Height
11.6 inch
Weight
29.1 lbs
Width
11.2 inch
Depth
19 inch
Color Category
Black, Gray
Compliant Standards
FCC Class B certified, RoHS
Energy Star
Yes
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 1 year
Limited Warranty
1 Year
Standby Power Consumption
9.6 watt
