Tech specs
Brand
HPE
Product Line
HPE StoreEasy
Model
1560
Manufacturer
Hewlett-Packard
Clock Speed
1.7 GHZ
Cores
6-core
Processor Brand
Intel
Processor Number
3104
Processor Type
Xeon Bronze
Processors Installed
1
Total Processor Supported
2
Features
HPE SmartMemory, Registered
Memory Technology
DDR4 SDRAM
RAM Installed
8 GB
Data Transfer Rate (Hard Drive)
600 MBps
Drive Interface
Serial ATA-600
Hard Drive Capacity
4 TB
Hard Drive Features
512 emulation ( 512e ), Digitally Signed Firmware, Midline
Port Expansion Hard Drive Type
HDD
Hot-Swap
Hot-swap
Installed Quantity
4
iSCSI support
iSCSI
Max Supported Capacity
64 TB
Network Storage Type
NAS server
Optical Drive Type
None
Rack-mountable
Rack-mountable
RAID Levels
RAID 0, RAID 1, RAID 1 ADM, RAID 10, RAID 10 ADM, RAID 5, RAID 50, RAID 6, RAID 60
Spindle Speed (rpm)
7200 revolutions per minute
Total Storage Capacity
16 TB
Type
RAID
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Host Connectivity (compact list)
Gigabit Ethernet
Network Services Compatibility
DHCP, DNS, FTP, FTPS, HTTP, HTTPS, Microsoft CIFS, Network File System (NFS), Server Message Block (SMB), Server Message Block 2.0 (SMB 2.0), Web-based Distributed Authoring and Versioning (WebDAV)
Expansion Bays
4 (total) / 0 (free) x hot-swap - 3.5" LFF
Expansion Slots
1 (total) / 1 (free) x PCI Express 3.0 x16 (full-length, full-height), 1 (total) / 1 (free) x PCI Express 3.0 x16 (three-quarter-length, full-height), 2 (total) / 1 (free) x CPU, 3 (total) / 2 (free) x PCI Express 3.0 x8 (half-length, full-height), 6 (total) / 5 (free) x DIMM 288-pin
Interface Provided
1 x HP iLO, 1 x HP iLO (management), 1 x HPE iLO, 1 x HPE iLO (management), 1 x USB 2.0, 1 x VGA, 2 x Ethernet 1000Base-T - RJ-45, 2 x USB 3.0
Frequency
50/60 hertz
Hot-Plug
Hot-plug
Nominal Voltage
AC 120/230 V
Power Provided
500 watt
Power Supplies Installed
1
Power Supplies Supported
2
Redundant Power Supply
Optional
Redundant Power Supply Supported
1+1 (with optional power supply)
80 PLUS Certification
80 PLUS Platinum
Software Type
HPE iLO Advanced Premium Security Edition with 1 Year Support
Storage Operating System
Microsoft Windows Storage Server 2016 Standard
Hard Drive Form Factor
3.5" LFF
Hard Drive Form Factor (metric)
8.9 cm LFF
Storage Controller Interface
Serial ATA-600 / SAS 3.0
Max Operating Temperature
95 degree Fahrenheit
Min Operating Temperature
50 degree Fahrenheit
Operating Humidity
8 - 90% (non-condensing)
Operation Type
Internal power supply
Supported Devices
4
Features
Padlock loop, Security lock slot (cable lock sold separately), Tower mountable, Trusted Platform Module (TPM) 2.0
Installed Devices/Modules
4
Packaged Quantity
1
Security Slot Type
Kensington security slot
Included Accessories
2 x non hot-plug redundant fans
Height
17.3 inch
Height (Rack Units)
4.5
Weight
29.76 lbs
Width
7.7 inch
Depth
18.9 inch
Compliant Standards
WEEE 2002/95/EC
Service & Support Details
Limited warranty - parts and labor - 3 years - on-site - response time: next business day, Limited warranty - software - 90 days
Integrated System
3-year warranty
