Tech specs
Brand
HPE
Product Line
HPE StoreEasy
Model
1860
Manufacturer
Hewlett-Packard
Clock Speed
1.9 GHZ
Cores
6-core
Processor Brand
Intel
Processor Number
3204
Processor Type
Xeon Bronze
Processors Installed
1
Total Processor Supported
2
Features
Registered
Memory Technology
DDR4 SDRAM
RAM Installed
16 GB
Data Transfer Rate (Hard Drive)
1.2 GBps
Drive Interface
Serial Attached SCSI 3
Hard Drive Capacity
1.2 TB
Hard Drive Features
Enterprise
Port Expansion Hard Drive Type
HDD
Installed Quantity
8
iSCSI support
iSCSI
Max Supported Capacity
67.2 TB
Network Storage Type
NAS server
Rack-mountable
Rack-mountable
RAID Levels
RAID 0, RAID 1, RAID 1 ADM, RAID 10, RAID 10 ADM, RAID 5, RAID 50, RAID 6, RAID 60
Spindle Speed (rpm)
10000 revolutions per minute
Total Storage Capacity
9.6 TB
Type
RAID
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Network Services Compatibility
DHCP, DNS, FTP, FTPS, HTTP, HTTPS, Microsoft CIFS, Network File System (NFS), Server Message Block (SMB)
Expansion Bays
24 (total) / 16 (free) x hot-swap - 2.5" SFF
Expansion Slots
1 (total) / 0 (free) x FlexibleLOM, 1 (total) / 0 (free) x PCI Express 3.0 x8 (half-length, full-height), 1 (total) / 1 (free) x PCI Express 3.0 x16 (full-length, full-height), 1 (total) / 1 (free) x PCI Express 3.0 x8 (full-length, full-height)
Interface Provided
1 x HP iLO, 1 x HPE iLO, 1 x VGA, 4 x Ethernet 1000Base-T - RJ-45
Frequency
50/60 hertz
Hot-Plug
Hot-plug
Nominal Voltage
AC 120/230 V
Power Provided
800 watt
Power Supplies Installed
2
Power Supplies Supported
2
Redundant Power Supply
Yes
Redundant Power Supply Supported
1+1
80 PLUS Certification
80 PLUS Platinum
Software Type
HPE iLO Advanced Premium Security Edition with 3 Years Support
Storage Operating System
Microsoft Windows Storage Server 2012 Standard
Hard Drive Form Factor
2.5" SFF
Hard Drive Form Factor (metric)
6.4 cm SFF
Storage Controller Interface
Serial ATA-600 / SAS 3.0
Max Operating Temperature
95 degree Fahrenheit
Min Operating Temperature
50 degree Fahrenheit
Operating Humidity
8 - 90% (non-condensing)
Operation Type
Internal power supply
Sound Emission
31 dBA
Supported Devices
24
Features
6 hot-swappable fans, Trusted Platform Module (TPM) 2.0
Installed Devices/Modules
8
Packaged Quantity
1
Included Accessories
6 x hot-plug redundant fans, Lockable security bezel
Height
3.4 inch
Height (Rack Units)
2
Weight
32.85 lbs
Width
17.5 inch
Depth
26.7 inch
Service & Support Details
Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Integrated System
3-year warranty
