Tech specs
Brand
HuddleCamHD
Product Line
HuddleCamHD
Model
SimplTrack 2
Manufacturer
PTZOptics
Host Interface
USB 3.0
Network Interface
Ethernet 10Base-T/100Base-TX
Connectivity Technology
Wired
Ports
3G-SDI - BNC, LAN - RJ-45, USB 3.0, VISCA input
Image Sensor Size
1/2.8"
Image Sensor Type
Exmor CMOS
Tilt
-30 to +90
Touchscreen
No
Camera Mechanical Design
Pan / tilt / zoom
Max Frame Rate
60 frames per second
Max Panning Speed (degree/sec)
120
Max Tilting Speed (degree/sec)
90
Max Video Resolution
1920 x 1080
Panning Range (degree)
-170 to +170
Video Capture
1920 x 1080 @ 60 fps
Video Modes
1080/60p
Video Signals
3G-SDI
Camera Type
Conference camera
Low Voltage Power
DC 12 V
Power Device Type
Power adapter
Rated Current
2.5 ampere
Angular Field of View (H, Max, Degree)
86
Angular Field of View (V, Max, Degree)
52
Power Device Form Factor
External
Indoor/Outdoor
Indoor
Max Focal Length
94 millimetre
Max Operating Temperature
104 degree Fahrenheit
Min Focal Length
4.7 millimetre
Min Operating Temperature
32 degree Fahrenheit
Minimum Illumination
0.5 lux
Operating System Required
Apple MacOS X, Google Chrome OS, Linux, Microsoft Windows 7 / 8 / 8.1 / 10
Optical Zoom
20
Sensor Size (metric)
9.1 mm (1/2.8")
Total Pixels
2,140,000 pixels
Video Input
Color
Features
256 preset positions, Auto tracking, Built-in 2.14 Mega Pixel Reference Camera
Packaged Quantity
1
Cables
1 x SuperSpeed USB cable - external - 10 ft, Control cable
Included Accessories
Remote control
Height
6.4 inch
Weight
2.65 lbs
Width
9.6 inch
Depth
5.7 inch
Color
Gray
Color Category
Gray
Compliant Standards
Plug and Play
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 1 year
Limited Warranty
1 Year
