Tech specs
Brand
i-Pro
Product Line
i-PRO
Model
WV-U31301-F2L
Manufacturer
i-PRO Americas
Memory Cards Supported
microSD Card, microSDHC Card, microSDXC Card
Network Interface
Ethernet 10Base-T/100Base-TX
Protocols
ARP, DDNS, DHCP, DHCPv6, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv6, LLDP, MLD, MQTT, NTP, RTCP, RTP, RTSP, SFTP, SMTP, SNMP 1, SNMP 2, SNMP 3, SRTP, SSL, TCP/IP, TLS, UDP/IP, UPnP
Connectivity Technology
Wired
Ports
LAN/power - RJ-45
Image Sensor Size
1/2.8"
Image Sensor Type
CMOS
Tilt
0 to 90
Audio Formats
AAC-LC, ADPCM, G.711, G.726
Audio Support
Yes
Audio Support Features
Built-in microphone
Camera Mechanical Design
Fixed
Digital Video Capture Resolution
1280 x 720, 1280 x 960, 1920 x 1080, 320 x 180, 640 x 360
Max Frame Rate
30 frames per second
Max Video Resolution
1920 x 1080
Motion Detection
Yes
Panning Range (degree)
-45 to +45
Recording Formats
JPEG
Shutter Speed (Max)
1/10000 second (time unit)
Shutter Speed (Min)
16/30 second (time unit)
Video Capture
1280 x 960 @ 25/30 fps, 1920 x 1080 @ 25/30 fps
Camera Type
Network surveillance camera
Night Vision
Yes
Low Voltage Power
DC 48 V / PoE
Power Consumption Operational
5.3 watt
Rated Current
110 milliampere
Angular Field of View (H, Max, Degree)
123
Angular Field of View (H, Min, Degree)
92
Angular Field of View (V, Min, Degree)
69
Focal Length Control
Fixed focal
Form Factor
Dome
Indoor/Outdoor
Indoor
Infrared Distance
69 ft
Infrared LEDs
Yes
Lens Aperture
F/2.1
Max Operating Temperature
104 degree Fahrenheit
Min Focal Length
2.4 millimetre
Min Focus Distance
1.6 ft
Min Operating Temperature
32 degree Fahrenheit
Minimum Illumination
0 lux - IR - F2.1 - 50 IRE - shutter 1/30 sec, 0.0031 lux - B&W - F2.1 - 50 IRE - shutter 16/30 sec, 0.0075 lux - color - F2.1 - 50 IRE - shutter 16/30 sec, 0.05 lux - B&W - F2.1 - 50 IRE - shutter 1/30 sec, 0.08 lux - color - F2.1 - 30 IRE - shutter 1/30 sec, 0.12 lux - color - F2.1 - 50 IRE - shutter 1/30 sec
Operating Humidity
10 - 90% (non-condensing)
Sensor Size (metric)
9.1 mm (1/2.8")
Total Pixels
2,000,000 pixels
Video Formats
H.264, H.265
Video Input
Color
Features
Adaptive Black Stretch (ABS), AI Analytics, Ambarella S3LM, Audio Detection, Automatic Tracing White (ATW), Automatic White Balance Control (AWC), Backlight Compensation (BLC), Digital Noise Reduction, Fog compensation, Highlight Compensation (HLC), ONVIF (Profile G) support, ONVIF (Profile S) support, ONVIF (Profile T) support, Privacy Zone, Scene Change Detection (SCD)
Packaged Quantity
1
Height
2 inch
Weight
9.88 ounce
Width
4.1 inch
Depth
4.1 inch
Color
White
Color Category
White
Compliant Standards
CSA C22.2 No. 62368-1, EN 55032 Class A, EN 55035, FCC Part 15 A, ICES-003 Class A, IEC 62262 IK10, IEC 62368-1, IEEE 802.1x, IEEE 802.3af, NDAA, UL 62368-1
