Tech specs
Brand
Mellanox
Product Line
Mellanox Spectrum-3
Model
MSN4600C
Manufacturer
MELLANOX TECHNOLOGIES INC
RAM Installed
8 GB
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3x
Features
Access Control List (ACL) support, Data Center Bridging Exchange (DCBX) support, DHCP relay, Enhanced transmission selection (ETS), Event log, Flow control, IGMP snooping, IPv6 support, LACP support, LLDP support, Load balancing, Multiple Spanning Tree Protocol (MSTP) support, Per-VLAN Rapid Spanning Tree (PVRST), Port mirroring, Priority-Based Flow Control (PFC), RADIUS support, Rapid Spanning Tree Protocol (RSTP) support, sFlow, Syslog support
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9216 bytes
Manageable
Yes
Ports
64
Product Type
Switch
Remote Management
CLI, HTTP, HTTPS, SNMP 1, SNMP 2, SNMP 3, Telnet
Routing Protocol
BGP, OSPFv2, Static IPv4 routing, VRRP
Subcategory
Network hubs and switches
Switching Type
100 Gigabit Ethernet
Interface Provided
1 x management (Gigabit LAN) RJ-45, 1 x serial RJ-45, 1 x USB, 64 x 100Gbit LAN QSFP28
Port Quantity
64
Port Type
100 Gigabit QSFP28
Frequency
50/60 hertz
Hot-Plug
Hot-plug
Power Supplies Installed
2
Power Supplies Supported
2
Redundant Power Supply
Yes
Redundant Power Supply Supported
1+1
Software Type
Mellanox Onyx
Built-in Devices
32 GB SSD
Max Operating Temperature
104 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
Operating Humidity
5 - 85%
Airflow Direction
Back to front airflow
Authentication Method
LDAP, RADIUS, Secure Shell v.2 (SSH2), TACACS+
Capacity
Packet buffer size: 64 MB
Device Type
Internal power supply
Packaged Quantity
1
Performance
Throughput: 12.8 Tbps
Rack Mounting Kit
Included
Included Accessories
Rack rails kit
Height
3.5 inch
Height (Rack Units)
2
Width
16.9 inch
Depth
22.4 inch
Color Category
Black
Compliant Standards
CB, cTUVus, FCC, ICES, RCM, VCCI
ENERGY STAR Certified
No
Service & Support Details
Limited warranty - 1 year
Limited Warranty
1-year warranty
