Tech specs
Brand
MGE
Product Line
MGE Galaxy
Model
3500 with 4 Battery Modules
Manufacturer
APC
Remote Management
HTTP, SNMP
Remote Management Interface
RS-232
Expansion Slots
SmartSlot
Interface Provided
1 x management (RS-232)
Batteries Quantity
4
Battery Recharge Time
5 Hours
Emergency Power Off
Built-in maintenance bypass, Built-in static bypass
Expandable Battery
Expandable
Frequency
40 - 70 hertz
Frequency Provided
57 - 63 hertz
Input Connector Type
Hardwire 5-wire (3PH + N + G)
Input Voltage Range
AC 160 - 240 V
Input Wiring
3-phase
Load Type
At full load
Max Run Time
27.7 min at full load
Output Connector Quantity
3
Output Connector Type
Hardwire 4-wire (3PH + G), Hardwire 5-wire (3PH + N + G), Terminal block (screw)
Power Capacity
15000 volt ampere per kilogram
Power Output Connectors Details
1 x hardwire 4-wire (3PH + G), 1 x hardwire 5-wire (3PH + N + G), 1 x terminal block (screw)
Power Provided
12 kilograms per millimetere
Provided Voltage
AC 120/208/220 volt
Required Voltage
AC 208 volt
UPS Technology
On-line
Waveform Type
Sinewave
Battery Run Time (Up To)
27.7 minute (time unit)
Software Type
Drivers & Utilities
Form Factor (Power Device)
External
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
0 - 95%
Sound Emission
51.3 dBA
Packaged Quantity
1
Product Type
UPS
Subcategory
UPS
Cables
Serial cable - external
Included Accessories
Bolt down brackets
Height
58.7 inch
Weight
1320.56 lbs
Width
20.6 inch
Depth
33 inch
Compliant Standards
cUL, ISO 14001, ISO 9001, UL 1778
Service & Support Details
Limited warranty - 1 year
Integrated System
1-year warranty
