Tech specs
Brand
MicroTouch
Product Line
MicroTouch
Model
MA-SCAN-A1
Manufacturer
MicroTouch
Connectivity Technology
Wired
Interface Required
1 x USB-C
Barcode Symbology Supported
Australian Post, Aztec code, British Post, Canadian Post, China Post, Chinese Sensible Code, Codabar, Codablock A, Codablock F, Code 11, Code 128, Code 2 of 5, Code 39, Code 93, Code 93i, Data Matrix, DotCode, EAN/JAN-13, EAN/JAN-8, Grid Matrix Code, Han Xin, IATA 2 of 5, Japanese Post, Kix (Netherlands) Post, Korea Post, MaxiCode, Micro PDF417, PDF417, PLANET, Postnet, QR code
Frame Rate
120 frames / sec
Scan Rate
236.2 inch / sec
Sensor Resolution
640 x 480
Form Factor
Plug-in module
Image Sensor Type
2D imager
Interface
USB-C
Max Operating Temperature
140 degree Fahrenheit
Min Operating Temperature
-22 degree Fahrenheit
Minimum Bar Width
3 milli-inch
Print Contrast Signal (PCS)
20%
Scanning Distance
29.4 inch
Scanner Functionality
Barcode scanner
Features
Human Interface Device Profile (HID)
Packaged Quantity
1
TTL Decoding
Decoded
Included Accessories
2 Mylar pads, 2 screws
Height
4 inch
Width
2.7 inch
Depth
1.6 inch
Color
Black
Color Category
Black
Compliant Standards
FCC, ISED
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
