Tech specs
Brand
NEC
Product Line
NEC
Model
NP-MC453X
Manufacturer
NEC Technologies
Connectivity Technology
Wired
Ethernet (LAN) Capability
Ethernet
LAN and Wireless Image Transferring Protocols
Wired LAN
LAN and Wireless Presentation
LAN
Interface Provided
1 x audio line-in - mini-phone stereo 3.5 mm, 1 x audio line-in - RCA x 2, 1 x audio line-out - mini-phone stereo 3.5 mm, 1 x composite video input - RCA, 1 x network - RJ-45, 1 x serial RS-232 - 9 pin D-Sub (DB-9) (management), 1 x USB - 4 pin USB Type A, 1 x USB - 4 pin USB Type B, 1 x VGA / component video input - 15 pin HD D-Sub (HD-15), 1 x VGA output - 15 pin HD D-Sub (HD-15), 2 x HDMI - 19 pin HDMI Type A
Bundled Services
3 years InstaCare Service
Video Interfaces
Component video, Composite video, HDMI, VGA
Form Factor
Integrated
Output Type
Speaker(s)
Speaker Output Mode
Mono
Speaker Output Power
16 watt
Video Modes
1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Brightness
4500 lumens
Contrast Ratio
16000:1
Display Resolution Abbreviation
XGA
Focus Type
Manual
Horizontal Keystone Correction
-30 / +30
Keystone Correction Direction
Horizontal, Vertical
Lamp Life Cycle
Up to 10000 hour(s) - normal mode, Up to 20000 hour(s) - economic mode
Max Diagonal Image Size
300 inch
Max Horizontal Sync
100 kilohertz
Max Projection Distance
36 ft
Max Resolution
1920 x 1200
Max Vertical Sync
120 hertz
Min Diagonal Image Size
29.9 inch
Min Projection Distance
3 ft
Native Aspect Ratio
4:3
Native Resolution
1024 x 768
Portability
Non-portable
Throw Ratio
1.5 - 1.8:1
Vertical Keystone Correction
-30 / +30
Zoom Factor
1.2x
Zoom Type
Manual
Frequency
50/60 hertz
Power Supply
AC
Software Type
NaViSet Administrator 2
Built-in Devices
Speaker
Controls & Adjustments
Keystone correction
Lamp Life
10000 hour(s)
Lamp Power
225 watt
Lens Aperture
F/1.6-1.76
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
41 degree Fahrenheit
Operating Humidity
20 - 80% (non-condensing)
Sound Emission
37 decibel
Sound Emission (Economic Mode)
29 decibel
Speakers
1 x mixed channel
Class
Digital projector
Packaged Quantity
1
Product Type
LCD projector
Projector Features
Advanced AccuBlend technology, Auto Power Off, AutoSense technology, Carbon Savings Meter, Cornerstone, Crestron RoomView, Eco Mode, High-bandwidth Digital Content Protection System (HDCP), PJlink, USB Viewer, Wall color correction
Recommended Use
Presentation and multimedia
Cables
1 x VGA cable
Included Accessories
Battery for remote control, Wireless remote control
Height
4.3 inch
Weight
7.05 lbs
Width
13.6 inch
Depth
10.3 inch
Color Category
White
Compliant Standards
CAN/CSA 62368-1, FCC Part 15 Class B, ICES-003 issue 6, UL 60950-1, UL 62368-1
ENERGY STAR Certified
No
TCO Certified
No
Service & Support Details
Limited warranty - exchange - 3 years - response time: next business day, Limited warranty - lamp - 1 year / 1000 hours
Limited Warranty
3 Year
Standby Power Consumption
0.5 watt
