Tech specs
Brand
NETGEAR
Product Line
NETGEAR Smart
Model
GS752TS
Manufacturer
NETGEAR
Flash Memory Installed
32 megabyte
Memory Technology
DDR SDRAM
RAM Installed
128 megabyte
Compliant Standards
IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features
Broadcast Storm Control, DHCP client, DHCP snooping, DoS attack prevention, Energy Efficient Ethernet, Firmware upgradable, Flow control, Full duplex mode, IGMP snooping, IPv6 support, Link Aggregation Control Protocol (LACP), LLDP support, MLD snooping, Multicast Storm Control, Multiple Spanning Tree Protocol (MSTP) support, Port mirroring, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, SNTP support, Static routing, VLAN support
Form Factor (Hubs & Switches)
Rack-mountable
MAC Address Table Size
16K entries
Manageable
Yes
Max Units In A Stack
6
Ports
48
Product Type
Switch
Remote Management
HTTP, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3
Routing Protocol
IGMP, IGMPv2, IGMPv3, MLD
Smart
Yes
Stackable
Stackable
Status Indicators
Fan, Link/activity, Port transmission speed, Power
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
QSFP Slots
Gigabit SFP
Interface Provided
4 x SFP (mini-GBIC), 50 x 1000Base-T RJ-45
Port Quantity
48
Port Type
10/100/1000
Ports Type (2nd)
Combo Gigabit SFP
Frequency
50 - 60 hertz
Power Consumption Operational
77 watt
Humidity Range Storage
5 - 95% (non-condensing)
Max Operating Temperature
122 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
-4 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Capacity
Virtual interfaces (VLANs): 256
Country
North America
Device Type
Internal power supply
Packaged Quantity
1
Ports (2nd) Quantity
2
Ports (3rd) Quantity
4
Rack Mounting Kit
Included
Height
1.7 inch
Height (Rack Units)
1
Weight
9.48 lbs
Width
17.3 inch
Depth
10.1 inch
Compliant Standards
CB, CCC, C-Tick, EN 60950, EN55022, EN55024, FCC Part 15 A, UL 60950, VCCI Class A ITE
Integrated System
NETGEAR lifetime warranty
