Tech specs
Brand
NVIDIA
Product Line
NVIDIA Quantum-2
Model
QM9700
Manufacturer
Nvidia Corp
Processor Brand
Intel
Processor Type
Core i3
Processors Installed
1
Memory Technology
DDR4 SDRAM
RAM Installed
8 GB
Features
Adaptive routing, Congestion control, Hot swappable fan, NVIDIA Scalable Hierarchical Aggregation and Reduction Protocol (SHARP), Quality of Service (QoS), RDMA support, Self-healing network, Top-of-Rack (ToR)
Form Factor (Hubs & Switches)
Rack-mountable
Manageable
Yes
Ports
32
Product Type
Switch
Remote Management
CLI, HTTP, JSON, SNMP
Smart
Yes
Subcategory
Network hubs and switches
Switching Type
InfiniBand
Interface Provided
1 x USB 3.0 management, 1 x USB management, 2 x management RJ-45, 32 x 400Gbit LAN OSFP
Port Quantity
32
Port Type
400 Gigabit OSFP
Hot-Plug
Hot-plug
Power Supplies Installed
2
Redundant Power Supply
Yes
Redundant Power Supply Supported
1+1
Required Voltage
AC 200-240 volt
80 PLUS Certification
80 PLUS Gold
Software Type
NVIDIA MLNX-OS
Built-in Devices
16 GB SSD
Form Factor (RAM)
SO-DIMM 260-pin
Max Operating Temperature
104 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
Operating Humidity
10 - 85% (non-condensing)
Airflow Direction
Back to front airflow
Device Type
Internal power supply
Packaged Quantity
1
Performance
Aggregate throughput: 51.2 Tbps, Packets per second: 66.5 Bpps, Performance per port: 400 Gbps
Height
1.7 inch
Height (Rack Units)
1
Weight
31.97 lbs
Width
17.2 inch
Depth
26 inch
Color Category
Black
Compliant Standards
CB, cTUVus, CU, FCC, ICES, RCM, RoHS, VCCI
ENERGY STAR Certified
Yes
Service & Support Details
Limited warranty - 1 year
Limited Warranty
1 Year
