Tech specs
Brand
Palo Alto Networks
Product Line
Palo Alto Networks
Model
PA-1410
Manufacturer
Palo Alto
Hard Drive Capacity
120 GB
Port Expansion Hard Drive Type
SSD
Installed Quantity
1
Compliant Standards
IEEE 802.1Q, IEEE 802.3ad (LACP)
Connectivity Technology
Wired
Data Link Protocols
10 Gigabit Ethernet, 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Features
151W PoE power budget, Data Loss Prevention (DLP), High Availability, HTTP/2 support, IPv6 support, Jitter/ loss/ latency measurement, Machine learning, Multi-factor authentication (MFA), NAT support, Path Selection, PoE up to 90 watts per port, Pre-Shared Key (PSK), SD-WAN support, Stateless Address Autoconfiguration (SLAAC), URL filtering, VLAN support, Web threat protection
Form Factor
Rack-mountable
Network Standard
DHCP, DNS, HTTP, IPSec, IPv4, IPv6, PPPoE
Power Over Ethernet (PoE)
PoE
Product Type
Security appliance
Routing Protocol
BGP, IGMP, IGMPv2, IGMPv3, OSPFv2, OSPFv3, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP, Static IP routing
Interface Provided
1 x 1000Base-T (management) - RJ-45, 1 x 10Gb Ethernet (HA), 1 x console - micro-USB, 1 x console - RJ-45, 1 x USB - Type A, 4 x 1/2.5/5GBase-T (PoE) - RJ-45, 4 x 1Gb Ethernet/10Gb Ethernet - SFP/SFP+, 6 x Ethernet 1000 - SFP, 8 x 1000Base-T - RJ-45
Frequency
50/60 hertz
Power Consumption Operational
250 watt
Power Provided
450 watt
Power Supplies Installed
1
Power Supplies Supported
2
Redundant Power Supply
Optional
Required Voltage
AC 100 - 240 volt
Encryption
128-bit AES, 192-bit AES, 256-bit AES, 256-bit SHA, 384-bit SHA, 3DES, 512-bit SHA, IKEv1, IKEv2, MD5, SHA-1, SSL, TLS 1.3
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
MTBF
24 years
Airflow Direction
Front to back airflow
Capacity
Maximum number of sessions: 945000, New sessions per second: 100000, Virtual systems (base): 1, Virtual systems (maximum): 6, VLAN tags per device: 4094, VLAN tags per interface: 4094
Device Type
Internal power supply
Packaged Quantity
1
Service Activation
No
Network Device
Firewall throughput (appmix): 6.8 Gbps, Firewall throughput (HTTP): 8.9 Gbps, Threat prevention throughput (appmix): 3.2 Gbps, Threat prevention throughput (HTTP): 3.3 Gbps, VPN throughput (IPSec): 4.6 Gbps
Height
1.7 inch
Height (Rack Units)
1
Weight
15.5 lbs
Width
17.2 inch
Depth
14.1 inch
Color Category
Silver
Compliant Standards
CB, cTUVus, FCC Class A certified, VCCI Class A
ENERGY STAR Certified
No
Service & Support Details
Limited warranty - 1 year
Limited Warranty
1-year warranty
