Tech specs
Brand
Promise
Product Line
Promise VTrak
Model
E5800FD
Manufacturer
Promise Technology
Bus Type
Fibre Channel
Data Transfer Rate
12 Gbit/s
HDD Array External Interface
16Gb Fibre Channel
HDD Array External Interface Class
Fibre Channel
Maximum LUNs
1024
Rack-mountable
Rack-mountable
RAID Levels
RAID 0, RAID 1, RAID 10, RAID 5, RAID 50, RAID 6, RAID 60
Storage Controller Type
RAID
Expansion Bays
24 (total) / 24 (free) x hot-swap - 3.5"
Interface Provided
1 x Ethernet 1000 (management) - RJ-45, 1 x serial RS-232 (management) - 9 pin D-Sub (DB-9), 2 x SAS 12Gb/s - 36 pin 4x Mini SAS HD (SFF-8644), 4 x 16Gb Fibre Channel - SFP (mini-GBIC)
Redundant Power Supply
Yes
80 PLUS Certification
80 PLUS Gold
Software Type
Command Line Interface (CLI), Promise WebPAM PROe
Storage Controller Interface
Serial ATA-600 / SAS 3.0
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
41 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Operating System Required
Apple MacOS X 10.x, Microsoft Windows Server 2008, Microsoft Windows Server 2012, Microsoft Windows Server 2012 with Hyper-V, Red Hat Enterprise Linux 6.5, Red Hat Enterprise Linux 6.6, SuSE Linux Enterprise Server 11, VMware ESX 6.0
Operation Type
Internal power supply
Sound Emission
55 decibel
Supported Devices
24
Supported Interface
Serial ATA-600 / SAS 3
Controllers Included
2
Features
Online Capacity Expansion (OCE), Predictive Data Migration (PDM), RAID Level Migration, SNMP support
Installed Devices/Modules
0
Packaged Quantity
1
Product Type
Hard drive array
Height
6.9 inch
Height (Rack Units)
4
Weight
65.26 lbs
Width
17.6 inch
Depth
20 inch
Color Category
Silver
Compliant Standards
BSMI, CB, cUL, EMC Class A, FCC, RCM, RoHS, TUV, UL, VCCI, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 3 years, Product info support - e-mail consulting - 3 years, Technical support - phone consulting - 3 years
Limited Warranty
3 Year
