Tech specs
Brand
Ruckus
Product Line
Ruckus ICX
Model
8200
Manufacturer
Ruckus Wireless
Flash Memory Installed
8 GB
RAM Installed
4 GB
Advanced Switching
Layer 3
Features
ARP support, BOOTP support, DDos attack prevention, DHCP support, Flow control, MAC address filtering, Metro Ring Protocol (MRP) support, PIM snooping, Rapid Spanning Tree Protocol (RSTP) support, sFlow, Spanning Tree Protocol (STP) support, VLAN support, Weighted Round Robin (WRR) queuing
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9216 bytes
MAC Address Table Size
32K entries
Manageable
Yes
Max Units In A Stack
12
PoE Budget
740 watt
Ports
48
Power Over Ethernet (PoE)
PoE+
Product Type
Switch
Remote Management
CLI, DHCP, SNMP 1, SNMP 2c, SNMP 3, SSH, SSH-2, Telnet
Routing Protocol
GRE, OSPF, Static IPv4 routing, Static IPv6 routing, VRRP
Stackable
Stackable
Subcategory
Network hubs and switches
Interface Provided
1 x RJ-45 out-of-band network management, 1 x serial (console) RJ-45 management, 1 x USB storage, 1 x USB-C console management, 4 x 25 GbE SFP28 uplink/stacking, 48 x 10/100/1000 Base-T (PoE+) RJ-45
Port Quantity
48
Port Type
10/100/1000 (PoE+)
Ports Type (2nd)
25 GbE SFP28 (stacking / uplink)
Frequency
50 - 60 hertz
Hot-Plug
Hot-plug
Power Provided
920 watt
Power Supplies Installed
1
Power Supplies Supported
2
Redundant Power Supply
Yes
Redundant Power Supply Supported
1+1
Required Voltage
AC 100-240 volt
Encryption
AES
Humidity Range Storage
10 - 90% (non-condensing)
Max Operating Temperature
113 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Airflow Direction
Front to back airflow
Authentication Method
RADIUS, Secure Shell v.2 (SSH2), TACACS, TACACS+
Capacity
Spanning Tree Protocol instances: 253, Virtual interfaces (VLANs): 4095
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding performance: 220 Mpps, Stacking bandwidth: 1.2 Tbps, Switching capacity: 296 Gbps
Ports (2nd) Quantity
4
Height
1.7 inch
Height (Rack Units)
1
Weight
14.09 lbs
Width
17.3 inch
Depth
14.6 inch
Color Category
Black
Compliant Standards
CAN/CSA-C22.2 No. 62368-1, EN 300 386, EN 55032, EN 55035, EN 61000-3-2, EN 61000-3-3, EN55024, FCC Part 15 B Class A, ICES-003, KN32 Class A, KN35 Class A, TCVN 7189 Class A, TCVN 7317, UL 62368-1, VCCI Class A
Service & Support Details
Limited warranty - lifetime, Limited warranty - technical support - 3 years
Limited Warranty
Limited Lifetime
