Tech specs
Brand
SIIG
Product Line
SIIG
Model
4K 60Hz HDMI over IP Matrix Transmitter
Manufacturer
Siig
Connectivity Technology
Wired
Data Link Protocols
HDMI, Infrared, RS-232
Extender Type
Transmitter
Features
1080i resolution support, 1080p resolution support, 18 Gbps bandwidth, 2160p resolution support, 480p resolution support, 4K resolution support, 7.1 channel audio support, 720p resolution support, AV Over IP, Bi-directional IR, Built-in DIP switch, HDR10 support, Metal housing, Multi-casting, One-to-Many, One-to-One, Video wall function, Wall mountable
Form Factor
External
Max Transfer Distance
394 ft
Product Type
Video/audio/infrared/serial extender
Status Indicators
Information, Link, Power
Transmission Medium
CAT 6/6a/7
Interface Provided
1 x audio (output) - mini jack female, 1 x audio (output) - TOSLINK female, 1 x HDMI (input) - 19 pin HDMI Type A female, 1 x IR (input) - mini jack female, 1 x IR (output) - mini jack female, 1 x microphone (input) - mini jack female, 1 x RS-232 - DB-9 female, 1 x video (output) - RJ-45 female, 2 x USB (input) - Type B female
KVP Max Resolution
4K
Frequency
50/60 hertz
Required Voltage
AC 100 - 240 volt
KVM V-Sync Rate At Max Resolution
60 Hz
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
5 - 90% RH (non-condensing)
Device Type
External power adapter
Packaged Quantity
1
Cables
1 x IR blaster cable
Included Accessories
2 screws
Height
1.1 inch
Weight
22.57 ounce
Width
6.8 inch
Depth
5.2 inch
Color
Black
Color Category
Black
Compliant Standards
FCC, HDCP 2.2, RoHS, UL
ENERGY STAR Certified
No
TAA Compliant
Yes
Service & Support Details
Limited warranty - 3 years
Limited Warranty
3 Year
