Tech specs
Brand
Soundcraft
Product Line
Soundcraft
Model
Ui24R
Manufacturer
Jbl Multimedia Speakers
Connector Type
1 x audio line-in (RCA x 2) - front, 1 x foot switch - side, 1 x HDMI (19 pin HDMI Type A) - side, 1 x main channel output (phone 6.3 mm x 2) - front, 1 x main channel output (XLR x 2) - front, 1 x USB (4 pin USB Type B) - front, 10 x balanced audio input (XLR / phone 6.3 mm) - front, 10 x balanced audio input (XLR) - front, 2 x headphones (phone stereo 6.3 mm) - front, 2 x network (RJ-45) - side, 2 x USB (4 pin USB Type A) - front, 2 x USB (4 pin USB Type A) - side, 8 x balanced audio output (XLR) - front
Channels
24-channel
Equalizer Bands
4
Features
Built-in channel compressors, Built-in compressor, Built-in de-esser, Built-in digital player, Built-in noise gate, Ethernet interface, Headphone output volume control, High pass filters, USB flash drive recording, USB interface, Wi-Fi networking capability
Headphones Output
Yes
Line Channels
1 stereo
Line Channels Connector
RCA x 2
Mic Channels
20 mono
Mic Channels Connector
XLR, XLR / phone 6.3 mm
Product Type
Digital mixer
Rack Mount
Rack-mountable
Height
10 inch
Weight
31.08 lbs
Width
22 inch
Depth
24 inch
Color Category
Black, Blue, White
ENERGY STAR Certified
No
