Tech specs
Brand
Synology
Product Line
Synology Disk Station
Model
DS1621+
Manufacturer
Synology
Clock Speed
2.2 GHZ
Cores
Quad-Core
Processor Brand
AMD
Processor Number
V1500B
Processor Type
Ryzen Embedded
Processors Installed
1
Total Processor Supported
1
Max Memory Supported
32 GB
Memory Technology
DDR4 SDRAM
RAM Installed
4 GB
iSCSI support
iSCSI
Network Storage Type
NAS server
RAID Levels
JBOD, RAID 0, RAID 1, RAID 10, RAID 5, RAID 6
Type
RAID
Compliant Standards
DLNA CERTIFIED
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Access Control List (ACL) support, Anti-virus protection, Apple Time Machine compatible, Cloud station server, DLNA Media Server, DLNA support, Download client, Failover protection, File sharing, Hardware encryption, High Availability, iSCSI LUN clone/snapshot, Link Aggregation, MailPlus server, OpenStack compatible, PXE support, Rsync compatible, SSD trim, Surveillance station, Synology Hybrid RAID, Syslog support, Trivial File Transfer Protocol (TFTP) support, VPN Server, VPN support, Wake On LAN (WOL), WebDAV server, Windows ODX
Host Connectivity (compact list)
Gigabit Ethernet
Network Services Compatibility
Apple File Protocol (AFP), Calendaring Extensions to WebDAV (CalDAV), File Level Security (ACLs), FTP, Microsoft Active Directory (AD), Microsoft CIFS, Network File System (NFS), Web-based Distributed Authoring and Versioning (WebDAV)
Network Standard
iSCSI
Remote Management
HTTP, HTTPS, SNMP, SSH, Telnet, TFTP
Expansion Bays
6 (total) / 6 (free) x hot-swap - 2.5" / 3.5"
Expansion Slots
1 (total) / 1 (free) x PCI Express 3.0 x8, 2 (total) / 1 (free) x DIMM 288-pin, 2 (total) / 2 (free) x M.2 2280
Interface Provided
2 x eSATA, 3 x USB 3.0 - Type A, 4 x Ethernet 1000Base-T - RJ-45
Frequency
50/60 hertz
Power Consumption Operational
51.22 watt
Power Provided
250 watt
Software Type
McAfee AntiVirus, Synology Central Management System
Built-in Devices
LED panel
Storage Controller Interface
Serial ATA-600
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
5 - 95%
Operation Type
Internal power supply
Sound Emission
25.2 dBA
Supported Devices
6
Features
Built-in 2 cooling fans, Citrix Ready, Security lock slot (cable lock sold separately), VMware Ready, Wake on LAN
Installed Devices/Modules
0
Packaged Quantity
1
Security Slot Type
Kensington security slot
Cables
2 x network cable
Included Accessories
Accessory pack
Height
6.5 inch
Weight
11.24 lbs
Width
11.1 inch
Depth
9.6 inch
Color
Black
Color Category
Black
Compliant Standards
BSMI, CCC, EAC, FCC, RCM, RoHS, VCCI
Service & Support Details
Limited warranty - 3 years
Limited Warranty
3 Year
Standby Power Consumption
25.27 watt
