Tech specs
Brand
Synology
Product Line
Synology FlashStation
Model
FS3600
Manufacturer
Synology
Clock Speed
2.1 GHZ
Cores
12-core
Max Turbo Speed
2.7 GHZ
Processor Brand
Intel
Processor Number
D-1567
Processor Type
Xeon
Processors Installed
1
Total Processor Supported
1
Features
ECC, Registered
Max Memory Supported
128 GB
Memory Technology
DDR4 SDRAM
RAM Installed
16 GB
iSCSI support
iSCSI
Network Storage Type
NAS server
Optical Drive Type
None
Rack-mountable
Rack-mountable
RAID Levels
JBOD, RAID 0, RAID 1, RAID 10, RAID 5, RAID 6, RAID F1
Total Storage Capacity
0 GB
Type
RAID
Data Link Protocols
10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Access Control List (ACL) support, Anti-malware protection, Antivirus analysis, Bandwidth control, B-tree file system (Btrfs), E-mail server, EXT4 file system, Failover protection, File station, Firewall protection, High Availability, iSCSI LUN clone/snapshot, LDAP support, Link Aggregation, MailPlus server, OpenStack compatible, Reset button, Surveillance station, VPN Server, VPN support, Wake On LAN (WOL), Windows ODX
Host Connectivity (compact list)
Gigabit Ethernet / 10 Gigabit Ethernet
Network Services Compatibility
Apple File Protocol (AFP), Calendaring Extensions to WebDAV (CalDAV), FTP, HTTPS, Microsoft Active Directory (AD), Network File System (NFS), Server Message Block (SMB), Web-based Distributed Authoring and Versioning (WebDAV)
Network Standard
FTP, HTTPs, iSCSI, L2TP, NFS, PPTP, SMB, SMTP
Remote Management
HTTPS, LDAP, SMTP, SNMP, SSH, Telnet
Expansion Bays
24 (total) / 24 (free) x hot-swap - 2.5"
Expansion Slots
1 x PCI Express 3.0 x8, 4 (total) / 3 (free) x DIMM 288-pin
Interface Provided
1 x serial - DB-9, 2 x Ethernet 10Gb - RJ-45, 2 x USB 3.0 - Type A, 4 x Ethernet 1000Base-T - RJ-45
Frequency
50/60 hertz
Power Consumption Operational
258.23 watt
Power Provided
500 watt
Power Supplies Installed
2
Power Supplies Supported
2
Encryption
AES-NI
Max Operating Temperature
95 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
5 - 95%
Operation Type
Internal power supply
Sound Emission
57 dBA
Supported Devices
24
Compression Format
H.264, H.265, MJPEG
Features
Built-in 4 cooling fans
Image Resolution
1280x720, 1920x1080, 2048x1536, 2591x1944, 3840x2160
Installed Devices/Modules
0
IP Cameras Supported
128
Packaged Quantity
1
Included Accessories
Accessory pack
Height
3.5 inch
Height (Rack Units)
2
Weight
32.85 lbs
Width
19 inch
Depth
28.5 inch
Color Category
Black
Compliant Standards
BSMI, EAC, FCC, RCM, RoHS, VCCI
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 5 years
Limited Warranty
5 Year
