Tech specs
Brand
Verkada
Product Line
Verkada Dome Series
Model
CD32-E
Manufacturer
Verkada Hardware
Memory Cards Supported
microSD Card, microSDHC Card, microSDXC Card
Network Interface
Ethernet 10Base-T/100Base-TX
Protocols
RTSP
Connectivity Technology
Wired
Ports
LAN - RJ-45
Image Sensor Size
1/2.8"
Image Sensor Type
CMOS
Tilt
60
Audio Support
Yes
Audio Support Features
Built-in microphone, One-way audio capability
Camera Mechanical Design
Fixed
Max Frame Rate
24 frames per second
Max Video Resolution
2048 x 1536
Motion Detection
Yes
Panning Range (degree)
355
Shutter Speed (Max)
1/10000 second (time unit)
Shutter Speed (Min)
1/30 second (time unit)
Camera Type
Network surveillance camera
Night Vision
Yes
Low Voltage Power
PoE
Angular Field of View (D, Min, Degree)
128
Angular Field of View (H, Min, Degree)
97
Angular Field of View (V, Min, Degree)
71
Camera Iris
Fixed iris
Focal Length Control
Fixed focal
Form Factor
Dome
Indoor/Outdoor
Outdoor
Infrared Distance
49 ft
Infrared LEDs
Yes
Lens Aperture
F/1.6
Max Operating Temperature
122 degree Fahrenheit
Min Focal Length
2.8 millimetre
Min Operating Temperature
14 degree Fahrenheit
Minimum Illumination
0 lux - IR, 0.009 lux - color - F1.9
Operating Humidity
0 - 90%
Protection
Vandal-resistant
Sensor Size (metric)
9.1 mm (1/2.8")
Total Pixels
3,000,000 pixels
Video Formats
H.264, H.265
Video Input
Color
Bundled With
30 days onboard storage (256GB)
Features
Adaptive quality recording, Ambarella CV25S88 CPU, Infrared-cut filter, Lens Distortion Correction, People analytics, People Detection, Progressive scanning, Vehicle analytics, Vehicle Detection, Wide Dynamic Range (WDR)
Packaged Quantity
1
Included Accessories
Cable gland wrench, Conduit adapter, Desiccant, Mounting template, Screw pack, Torx T10 screw driver, Wall mount (with screws and wall anchors)
Height
3.9 inch
Weight
29.87 ounce
Width
5.7 inch
Depth
5.7 inch
Color Category
Black, White
Compliant Standards
BIS, CB, FCC, IEEE 802.3af, IK10, IP67, KCC, NOM, UL
Service & Support Details
Limited warranty - 10 years
Limited Warranty
10 Year
