Tech specs
Brand
Zebra
Product Line
Zebra
Model
ZD611d
Manufacturer
Zebra Technologies
Flash Memory Installed
512 megabyte
Memory Technology
SDRAM
RAM Installed
256 megabyte
Product Type
Print server
Interface
Bluetooth 4.2, LAN, Serial, USB 2.0, USB host, Wi-Fi(ac)
Interface Required Connections
1 x LAN - RJ-45, 1 x RS-232 - 9 pin D-Sub (DB-9), 1 x USB 2.0 - 4 pin USB Type B, 1 x USB host - 4 pin USB Type A
Max B/W Print Resolution
300 dpi
Max H-Document Size
2.2 in
Max Mono Print Speed
359.1 Inches per minute
Max Print Length
39 inch
Max Print Size
Roll (2.35 in)
Max Roll Diameter
5 inch
Max V-Document Size
39 in
Maximum Print Width
2.13 inch
Media Thickness Range
0.06 mm - 0.1905 mm
Min H-Document Size
0.59 in
Min V-Document Size
0.25 in
Print Output Type
Monochrome
Print Speed
Up to 359.1 inch/min - max speed - 300 dpi
Wireless Print Technology
Wired, Wireless
Wireless Print Technology Ready
Yes
Barcode Symbology Supported
Aztec, Codabar, CODABLOCK, Code 11, Code 128, Code 39, Code 49, Data Matrix, EAN Composites, EAN-13, EAN-8, Industrial 2 of 5, Interleaved 2 of 5, ISBT 128, LOGMARS, MaxiCode, Micropdf, MSI, PDF417, PLANET, Plessey, Postnet, QR code, Standard 2 of 5, UPC, UPC-A, UPC-E
Media Feeders
1 x manual - 1 roll - Roll (2.35 in)
Media Size Class
Other
Media Sizes
Roll (0.59 in - 2.36 in)
Media Type
Other
Frequency
50/60 hertz
Power Device Type
Power supply
Power Factor Correction (PFC)
Yes
Required Voltage
AC 100-240 volt
Software Type
Link-OS
Power Device Form Factor
External
Language Emulation
EPL2, Extensible Mark-up Language (XML), PDF Direct, ZBI, ZPL II
Max Operating Temperature
105.8 degree Fahrenheit
Media Type
Black mark labels, Continuous labels, Die cut labels, Linerless labels, Receipt paper, Tag stock, Wristband labels
Min Operating Temperature
39.9 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Roll Core Diameter
0.5 in, 1 in, 1.5 in, 2 in, 3 in
Built-in Devices
4.3 inch LCD touch screen
Label Printer Features
Print Touch tag, Realtime clock, Reflective/black mark sensor, Transmissive/gap sensor
Office Machine Type
Printer
Printer Product Type
Label printer
Scanner Functionality
None
Features
Printer setup mobile app via BLE connection
Printer Functions
Printer
Packaged Quantity
1
Print Technology
Direct Thermal
Fonts Included
16 x bitmapped ZPL II, 2 x scalable ZPL, 5 x expandable EPL2
Printer Accessories Included
Empty ribbon take-up core
Height
5.9 inch
Weight
2.36 lbs
Width
4.5 inch
Depth
8.7 inch
Color Category
Gray
Compliant Standards
BIS, BSMI, CCC, C-Tick, cTUVus, CU, EN 300 328, EN 301 893, EN 61000-3-2, EN 62311, EN55022 Class B, EN55024, EN55035, EN61000-3-3, FCC Class B certified, FCC Part 15.209, FCC Part 15.247, ICES-003, IEC 60950-1, IEC 62368-1, INMETRO, KCC, NOM, REACH 2006/1907, RoHS 2011/65/EU Amendment 2015/863, RSS-247, S Mark, SABS, VCCI
Energy Star
Yes
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 2 years
Limited Warranty
2 Year
