Tech specs
Brand
Zebra
Product Line
Zebra
Model
ZT610
Manufacturer
Zebra Technologies
Clock Speed
800 megahertz
Processor Type
Cortex-A9
Flash Memory Installed
2 GB
Memory Technology
SDRAM
RAM Installed
1 GB
Product Type
Print server
Interface
Bluetooth 4.0, Gigabit LAN, NFC, Serial, USB, USB host
Interface Required Connections
1 x Gigabit LAN - RJ-45, 1 x RS-232 - 9 pin D-Sub (DB-9), 1 x USB - 4 pin USB Type B, 2 x USB host - 4 pin USB Type A
Fonts
CG Triumvirate Bold Condensed, OCR-A, OCR-B
Max B/W Print Resolution
300 dpi
Max H-Document Size
4.5 in
Max Mono Print Speed
720.5 Inches per minute
Max Print Length
100 inch
Max Print Size
Roll (4.5 in)
Max Roll Diameter
8 inch
Maximum Print Width
4.09 inch
Media Thickness Range
0.003 in - 0.012 in
Min H-Document Size
0.79 in
Min V-Document Size
0.118 in
Print Output Type
Monochrome
Print Speed
Up to 720.5 inch/min - max speed
Wireless Print Technology
Wired, Wireless
Wireless Print Technology Ready
Yes
Barcode Symbology Supported
Aztec code, Codabar, CODABLOCK, Code 11, Code 128A, Code 128B, Code 128C, Code 39, Code 49, Code 93, Data Matrix, EAN-13, EAN-8, Industrial 2 of 5, Interleaved 2 of 5, ISBT 128, LOGMARS, MaxiCode, MicroPDF417, MSI, PDF417, PLANET, Plessey, Postnet, QR code, RSS-14, Standard 2 of 5, TLC39, UPC-A, UPC-E
Media Feeders
1 x manual - 1 roll - Roll (4.5 in)
Media Size Class
Other
Media Sizes
Roll (0.79 in - 4.49 in)
Media Type
Other
Frequency
50/60 hertz
Power Device Type
Power supply
Power Factor Correction (PFC)
Yes
Power Device Form Factor
Internal
Display Graphic Resolution
240 x 320
Language Emulation
Extensible Mark-up Language (XML), ZPL, ZPL II
Max Operating Temperature
104 degree Fahrenheit
Media Type
Continuous labels, Die cut labels
Min Operating Temperature
41 degree Fahrenheit
Operating Humidity
20 - 85% (non-condensing)
RFID Compliant Standards
EPC Class 1 Generation 2, ISO/IEC 18000-63, RAIN
Roll Core Diameter
3 in
Built-in Devices
Status LCD, Tear bar, UHF RFID encoder
Country
United States
Label Printer Features
Realtime clock, Reflective media sensor, Tear bar, Transmissive media sensor
Office Machine Type
Printer
Printer Product Type
Label printer
Scanner Functionality
None
Features
Clear door
Printer Functions
Printer
Packaged Quantity
1
Print Technology
Direct Thermal, Thermal Transfer
Printer Features
Multi-level Element Energy Equalizer (E3), RFID ready
Text Styles
Mirror, Rotated text
Fonts Included
16 x bitmapped, 2 x scalable
Printer Accessories Included
Bi-fold door, Spindle
Height
15.6 inch
Weight
50.04 lbs
Width
10.6 inch
Depth
19.9 inch
Color Category
Black, Silver
Compliant Standards
BSMI, CCC, C-Tick, cTUVus, EN 61000-3-2, EN 61000-3-3, EN55022 Class B, EN55024, FCC Class B certified, GOST-R, ICES-003, IEC 60950-1, KCC, NOM, S Mark, UkrSEPRO, VCCI
Energy Star
Yes
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
