Tech specs
Brand
Axis
Product Line
AXIS
Model
Midspan
Manufacturer
Axis Communications
Compliant Standards
IEEE 802.3af, IEEE 802.3at
Power Over Ethernet (PoE)
PoE+
Input Connectors
1
Interface Provided
1 x Gigabit LAN - RJ-45
Frequency
47 - 63 hertz
Input Connector Type
Power IEC 60320 C14
Output Connector Quantity
1
Power Output Connectors Details
1 x RJ-45
Power Provided
30 watt
Provided Voltage
DC 56 volt
Required Voltage
AC 100-240 volt
Form Factor (Power Device)
External
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
-4 degree Fahrenheit
Operating Humidity
95% (non-condensing)
Country
United States
Features
DIN rail mountable, Wall Mountable
Packaged Quantity
1
Product Type
PoE Injector
Subcategory
Power converters, splitters and accessories
Cables
Power cable (C13) - external
Height
1.2 inch
Weight
5.11 ounce
Width
1.8 inch
Depth
5.5 inch
Color
Black
Color Category
Black
Compliant Standards
AS/NZS CISPR 32 Class A, CCC, CISPR 24, EAC, EN 55032 Class A, EN 61000-6-1, EN 61000-6-2, EN55024, FCC Part 15 B Class A, ICES-3(A)/NMB-3(A), IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IS13252, KCC KN32 Class A, KCC KN35, Plug and Play, RCM, UL 60950-1, UL 62368-1, VCCI Class A
Service & Support Details
Limited warranty - 3 years
Limited Warranty
3 Year
Compatibility Specs
AXIS A1601 Network Door Controller, A1610-B, A8207-VE MkII Network Video Door Station, A8207-VE Network Video Door Station, C1410, C1410 Network Mini Speaker, D2110-VE Security Radar, D3110, I8016-LVE, M1134, M1134 Barebone, M1135, M1135 Barebone, M1135-E, M1137, M1137 Barebone, M1137-E, M3015 Network Camera, M3016 Network Camera, M3057-PLVE MkII, M3057-PLVE Network Camera, M3058-PLVE Network Camera, M3064-V, M3065-V, M3066-V, M3067-P, M3068-P, M3075-V, M3077-PLVE, M3115-LVE, M3116-LVE, M3205-LVE, M3205-LVE Network Camera, M3206-LVE, M4206-LV Network Camera, M4206-V Network Camera, M4308-PLE, M5055, M7104 Video Encoder, P1375 Network Camera, P1375 Network Camera (Barebone), P1375-E, P1375-E Barebone, P1377, P1377 Barebone, P1377-LE, P1377-LE Barebone, P1378 Network Camera, P1378 Network Camera (Barebone), P1378-LE Network Camera, P1385-E, P1455-LE, P1455-LE-3 License Plate Verifier Kit, P3245-LV Network Camera, P3245-LVE Network Camera, P3245-V Network Camera, P3245-VE Network Camera, P3247-LVE, P3248-LV, P3248-LVE, P3715-PLVE, P3717-PLE, P3719-PLE, P3807-PVE Network Camera, P3818-PVE, P3905-R Mk II (Barebone), P3905-R Mk II M12 (Barebone), P3925-R, P3935-LR, P5654-E 50 Hz, P5654-E 60 Hz, P5655-E 50 Hz, P5655-E 60 Hz, P7304 Video Encoder, P9106-V, Q1615 Mk III, Q1615 Mk III Barebone, Q1615 MkIII Network Camera, Q1615-LE Mk III, Q1645, Q1645-LE Network Camera, Q1647, Q1647-LE, Q1659 Barebone, Q1700-LE License Plate Camera, Q1715, Q1785-LE, Q1786-LE, Q1798-LE, Q1952-E, Q3515-LV, Q3517-SLVE, Q3518-LVE, Q3527-LVE, Q3536-LVE, Q3538-LVE, Q6074, Q6074 50 Hz, Q6074 60 Hz, Q6074-E 50 Hz, Q6074-E 60 Hz, Q6075 50 Hz, Q6075 60 Hz, Q6075-E, Q6075-E 50 Hz, Q6075-E 60 Hz, Q6075-S, Q6075-S 60 Hz, Q6075-SE, Q6154-E 50Hz, Q6154-E 60Hz, Q9216-SLV Steel, Q9216-SLV White, W400 ¦ AXIS ExCam XF M3016 Explosion-Protected Network Camera, XF Q1645, XF Q1645 Explosion-Protected Network Camera, XPT Q6075 ¦ AXIS P37 Series P3727-PLE, P3737-PLE
