Tech specs
Brand
Axis
Product Line
AXIS
Model
P1455-LE
Manufacturer
Axis Communications
Flash Memory Installed
512 megabyte
Memory Cards Supported
microSD Card, microSDHC Card, microSDXC Card
RAM Installed
1024 megabyte
Network Interface
Ethernet 10Base-T/100Base-TX/1000Base-T
Protocols
ARP, Bonjour, CIFS, DDNS, DHCP, DNS, EAP, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, LLDP, MQTT, NTP, QOS, RTCP, RTP, RTSP, SFTP, SMB, SMTP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, SRTP, SSH, SSL, TCP/IP, TLS, UDP/IP, UPnP, USGv6
Connectivity Technology
Wired
Ports
Audio line-in/microphone - 3.5 mm jack, LAN/power - RJ-45
Image Sensor Size
1/2.8"
Image Sensor Type
RGB CMOS
Audio Formats
AAC-LC, ADPCM, G.726, LPCM, OPUS, PCM
Audio Support
Yes
Audio Support Features
Two-way audio capability
Camera Mechanical Design
Fixed
Digital Video Capture Resolution
160 x 90, 1920 x 1080
Max Frame Rate
60 frames per second
Max Video Resolution
1920 x 1080
Motion Detection
Yes
Shutter Speed (Max)
1/66500 second (time unit)
Shutter Speed (Min)
2 second (time unit)
Still Image Capture Resolution
1080p
Video Modes
1080p
Camera Type
Network surveillance camera
Night Vision
Yes
Low Voltage Power
PoE Class 3
Power Consumption Operational
12.95 watt
Software Type
Windows decoder 1-user license
Angular Field of View (H, Max, Degree)
114
Angular Field of View (H, Min, Degree)
37
Angular Field of View (V, Max, Degree)
58
Angular Field of View (V, Min, Degree)
21
Auto Iris Control
P-Iris
Camera Iris
Auto iris
Focal Length Control
Vari-focal
Indoor/Outdoor
Outdoor
Infrared Distance
131 ft
Lens Aperture
F/1.6
Max Focal Length
9 millimetre
Max Operating Temperature
140 degree Fahrenheit
Min Focal Length
3 millimetre
Min Operating Temperature
-40 degree Fahrenheit
Minimum Illumination
0 lux - IR, 0.01 lux - B&W - F1.6 - 50 IRE, 0.07 lux - color - F1.6 - 50 IRE
Operating Humidity
10 - 100%
Optical Zoom
3
Sensor Size (metric)
9.1 mm (1/2.8")
Total Pixels
2,000,000 pixels
Video Formats
AVC, H.264, H.265, HEVC, MJPEG, MPEG-4
Video Input
Color
Alarm Input Quantity
1
Alarm Output Quantity
1
Features
Adaptive Bitrate (ABR), Audio Detection, Brightness control, Contrast control, Digital PTZ function, Digital zoom, Exposure control, Forensic WDR, Image mirror, Image overlay, Infrared-cut filter, IR Corrected lens, Lightfinder 2.0 technology, ONVIF (Profile G) support, ONVIF (Profile S) support, ONVIF (Profile T) support, OptimizedIR, Privacy Mask Function, Progressive scanning, Remote focus, Sharpness control, Shock detection, Variable Bit Rate (VBR), White balance, Zipstream technology
Packaged Quantity
1
Included Accessories
Connector kit, Drill hole template, Mounting bracket, Torx L-key, Weathershield
Height
5.2 inch
Weight
2.2 lbs
Width
5.2 inch
Depth
10.2 inch
Color
White
Color Category
White
Compliant Standards
AS/NZS CISPR 32 Class A, EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 B Class A, ICES-3(A)/NMB-3(A), IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC 62236-4, IEC 62471, IEC/EN 60529 IP66, IEC/EN 60529 IP67, IEC/EN 62262 IK10, IEC/EN/UL 60950-22, IEC/EN/UL 62368-1, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IS13252, NEMA TS-2 (2.2.7-2.2.9), NEMA250 Type 4X, NIST SP500-267, RCM, VCCI Class A
Service & Support Details
Limited warranty - 5 years
Limited Warranty
5 Year
