Tech specs
Brand
Axis
Product Line
Axis
Model
T8508
Manufacturer
Axis Communications
Compliant Standards
IEEE 802.1ab (LLDP), IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, UPnP
Features
802.1x authentication, Access Control List (ACL) support, ARP support, Bridge protocol data unit (BPDU), DHCP server, DHCP snooping, DHCP support, Fanless, HTTPS encryption, Internet Control Message Protocol (ICMP), IP address filtering, IPv4 support, IPv6 support, LLDP support, LLDP-MED, Multiple Spanning Tree Protocol (MSTP) support, Network Access Control (NAC), Network Timing Protocol (NTP), Private VLAN, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Spanning Tree Protocol (STP) support, Surge protection, VLAN support
Form Factor (Hubs & Switches)
Desktop, Rack-mountable
Jumbo Frame Support
9216 bytes
MAC Address Table Size
8K entries
Manageable
Yes
PoE Budget
130 watt
Ports
8
Power Over Ethernet (PoE)
PoE+
Product Type
Switch
Remote Management
HTTP, HTTPS, SMTP, SNMP 1, SNMP 2c, SNMP 3, SSH, TFTP
Routing Protocol
IGMP
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
Interface Provided
2 x RJ-45/SFP, 8 x 10/100/1000 Base-T RJ-45 PoE+ / uplink - 30 W
Port Quantity
8
Port Type
10/100/1000 (PoE+)
Ports Type (2nd)
Combo Gigabit Ethernet/Gigabit SFP
Frequency
50/60 hertz
Humidity Range Storage
5 - 95% (non-condensing)
Max Operating Temperature
122 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
14 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Country
United States
Device Type
Internal power supply
Packaged Quantity
1
Performance
Switching capacity: 20 Gbps, Throughput: 14.9 Mpps
Ports (2nd) Quantity
2
Rack Mounting Kit
Optional
Included Accessories
4 rubber feet, Drill template
Height
1.7 inch
Weight
4.63 lbs
Width
8.7 inch
Depth
9.5 inch
Color
Black
Color Category
Black
Compliant Standards
AS/NZS CISPR 32 Class A, EAC, EN 55032 Class A, EN55024, FCC Part 15 B Class A, ICES-003 Class A, IEC/EN/UL 60950-1, JATE, SASO, VCCI Class A
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 3 years
Limited Warranty
3 Year
Compatibility Specs
AXIS A1610-B, C1410, D3110, M3067-P, M3068-P, P1385-E, P1455-LE, P1455-LE-3 License Plate Verifier Kit, W400 ¦ AXIS Camera Station S1216 Recording Server, S1232, S1296
