Tech specs
Brand
Canon
Product Line
Canon VB
Model
H45B
Manufacturer
Axis Communications
Memory Cards Supported
SD Memory Card, SDHC Memory Card, SDXC Memory Card
Network Interface
Ethernet 10Base-T/100Base-TX
Protocols
ARP, DHCP, DNS, EAP, FTP, HTTP, ICMP, IPv4, IPv6, NTP, POP3, RTCP, RTP, RTSP, SMTP, SNMP 1, SNMP 2c, SNMP 3, SSL, TCP/IP, TLS, UDP/IP, WV-HTTP
Connectivity Technology
Wired
Ports
Audio line out - 3.5 mm mono jack, Audio line-in/microphone - 3.5 mm mono jack, LAN/power - RJ-45
Image Sensor Size
1/3"
Image Sensor Type
CMOS
Tilt
-90 to +10
Audio Support
Yes
Audio Support Features
Two-way audio capability
Camera Mechanical Design
Pan / tilt / zoom
Digital Video Capture Resolution
1280 x 720, 1280 x 960, 1920 x 1080, 320 x 180, 320 x 240, 480 x 270, 640 x 360, 640 x 480, 960 x 540
Digital Zoom
20
Max Frame Rate
30 frames per second
Max Panning Speed (degree/sec)
150
Max Tilting Speed (degree/sec)
150
Max Digital Video Resolution
1920 x 1080
Panning Range (degree)
-170 to +170
Shutter Speed (Max)
1/16000 second (time unit)
Shutter Speed (Min)
1 second (time unit)
Video Capture
1920 x 1080 @ 30 fps
Camera Type
Network surveillance camera
Night Vision
Yes
Low Voltage Power
DC 12 V / AC 24 V / PoE Plus
Power Consumption Operational
9.9 watt
Software Type
Canon Camera Management Tool, Drivers & Utilities, RM-Lite
Angular Field of View (H, Max, Degree)
60.4
Angular Field of View (H, Min, Degree)
2.4
Angular Field of View (V, Max, Degree)
35.1
Angular Field of View (V, Min, Degree)
1.8
Battery Form Type
None
Focal Length Control
Motorized zoom
Focus Modes
Automatic, Manual
Lens Aperture
F/1.6-3.5
Max Focal Length
94 millimetre
Max Operating Temperature
122 degree Fahrenheit
Min Focal Length
4.7 millimetre
Min Focus Distance
11.8 inch
Min Operating Temperature
14 degree Fahrenheit
Minimum Illumination
0.003 lux - B&W - F1.6 - 50 IRE - shutter 1/30 sec / SSC off, 0.05 lux - color - F1.6 - 50 IRE - shutter 1/30 sec / SSC off
Operating Humidity
5 - 85% (non-condensing)
Optical Zoom
20
Sensor Size (metric)
8.5 mm (1/3")
Total Pixels
2,100,000 pixels
Video Formats
H.264, MJPEG
Video Input
Color
Alarm Input Quantity
2
Alarm Output Quantity
2
Features
64 preset positions, Abandoned Object Detection, Area-Specific Data Size Reduction (ADSR), Auto exposure control, Auto Smart Shade Control (Auto-SSC), Auto white balance, Camera Tampering Detection, DIGIC DV III, DIGIC NET II, Event Notification, Exposure compensation, Haze compensation, I-Frame Interval, Image stabilizer, Infrared cut filter, Intrusion detection, Motion Adaptive Digital Noise Reduction, Moving Object Detection, ONVIF (Profile S) support, Passing Detection, Primary color filter, Privacy Mask Function, Progressive scanning, Removed Object Detection, Scream detection, Smart Shade Control (SSC), Volume Detection
Packaged Quantity
1
Height
6.1 inch
Weight
2.51 lbs
Width
5.2 inch
Depth
5.2 inch
Color
Black
Color Category
Black
Compliant Standards
AS/NZS, CNS 13438 Class B, EN 50581, EN 55032 Class B, EN 60950-1, EN55024, FCC Part 15 Class B, ICES-003 Class B, IEC 60950-1, IEEE 802.3at, KN22 Class B, KN24, RCM, UL 60950-1, VCCI Class B
